DIMENSIONS
General
Length Overall (L.O.A.):
- 163.89 feet
- (49.95 meters)
Length at Waterline (L.W.L):
- 140.30 feet
- (42.76 meters)
Beam (max):
Beam (moulded):
Draft (full load):
Tonnage 498 gross
Capacities
Fuel Capacity:
- 21,926 US Gallons
- (83,000 liters)
Water Capacity:
- 5,548 US Gallons
- (21,000 liters)
Watermakers:
- 4,955 US Gallons
- (18,758 liters)
Lube Oil
- 264 US Gallons
- ( 1,000 liters)
Waste Oil:
- 259 US Gallons
- ( 980 liters)
Speed
Maximum:
- 16.2 knots
- Consumption: 119 US Gallons /hr (452 LPH)
- Range: 1,800 nm
- RPM: 1,700
Cruising:
- 11.5 knots
- Consumption: 53 US Gallons /hr (200 LPH)
- Range: 3,800 nm
- RPM: 1,120
Economical:
- 10.0 knots
- Consumption: 42 US Gallons /hr (160 LPH)
- Range: 4,600 nm
- RPM: 1,050
MACHINERY
Main Engines
Engine Type: (2) Caterpillar 3512C diesels @ 2,366 Hp each
Gearboxes for Main Engines: ZF 7646, RR 4.2:1
Drive: Shaft
Propulsion: Fixed screw propellers, stainless steel
Engines Exhaust System: Marquip
Generators & Electricity
Generators: (2) 118 kW Zenoro, John Deere generators, replaced 2022
Generator Fuel Consumption: 20 liters per hour
Shore Power: Insulation transformer only and Deiff sync unit
Batteries:
• (8) Zenith 12V AGM (engine start) – replaced (4) starboard side 2024
• (4) Zenith 12V AGM (service) – replaced 2024
• (2) Nautik 12V emergency diesel pump starting
• (1) Haze 12V UPS
• (32) UPS batteries - replaced 2025
Battery Chargers:
• (5) mastervolt 24V
• (2) Sailor 24V (radio batteries)
• (1) mastervolt 12V (emergency diesel pump)
Air Conditioning
Type: Heinen & Hopman fan coil system
Other Machinery
Watermakers: (2) Octomarine
Stabilizers: (2) fin Quantum Zero Speed QC1500, rebuilt in 2019
Bow Thruster: (1) 90 kW Naiad, replaced in 2024
Steering System: Opem
Fuel Separator & Filtration:
- Fuel filters
- (1) Alfa Laval PA600 fuel oil separator
- (2) transfer pumps
Sewage System: Tecnicomar
Hot Water System:
- (2) hot water circulation pumps
- (2) Giannesci hot water boilers
Bilge Water Filtration:
- Dvz oily bilge water separator
- Garbarino bilge pump
COMMUNICATION & NAVIGATION SYSTEMS
Communication Systems
SATcom:
• Seatel 5004
Vsat:
• Seatel
Inmarsat-C:
• Seatel
ECDIS:
• Transas
Satellite Phone:
• Thrane & Thrane
Telephone System:
• Panasonic
SSB:
• Sailor
VHF:
• Sailor
Portable VHF:
• Sailor
Intercom — Talk Back:
• Vingtor
Intercom:
• Panasonic
VHS Digital Radios:
• Sailor
Radio Transponders:
• Sailor
Navtex Receiver:
• Thrane & Thrane
GMDDS Battery Plant:
• General ship’s battery UPS system, 1,4 kW
Internal Ship’s Communication:
• Panasonic
Internet:
• Starlink -2024
Control Operating System:
• Kerio - 2024
Navigation Systems
Monitors:
• Hatteland 4 PCS
Radar:
• Furuno
Gyrocompass:
• Navigat X MK 2
Magnetic Compass:
• Sperry Marine
Auto Pilot:
• Sperry Marine
Depth Sounder:
• B&G
Echo Sounder:
• Skipper
Wind Instruments:
• B&G
DGPS:
• Simrad
GPS:
• Simrad
AIS:
• Transas
Weather FAX:
• Sialor
Ships Computer:
• HP
Chart Plotter:
• Transas and Simrad (Navionics)
Speed Log:
• Sperry Marine
Navtex:
• Thrane & Thrane
UPS:
• General Ships UPS 1,4 kW
Bridge Navigation Watch Alarm:
• Onyx Marine
Tender Trackign System:
• AIS
Horn:
• (1) E/Pneumatic Khalenberg T3A
Search Lights:
• (1) Carlisle & Finch 200W Xenon Lamp
Entertainment System:
a. Video Equipment
TV’s: • Panasonic Plasma – 2012 – upper deck salon
• Apple TV, Plex and DUNA system
b. Audio Equipment
Stereo’s: • 2012 – upper deck salon, bridge deck aft,sundeck
