CONSTRUCTION
Steel hull and superstructure, teak decks
DIMENSIONS
General
Length Overall (L.O.A.):
- 117.08 feet
- (35.69 meters)
Length at Waterline (L.W.L.):
- 101.00 feet
- (30.78 meters)
Beam (molded):
Draft (loaded):
Tonnage:
Capacities
Fuel Capacity:
- 13,366 US Gallons
- (50,596 liters)
Water Capacity:
- 1,278 US Gallons
- (4,838 liters)
Black Water:
- 1,420 US Gallons
- (5,405 liters)
Lube Oil:
- 328 US Gallons
- (1,241 liters)
Waste Oil:
- 166 US Gallons
- ( 628 liters)
Speed
Maximum:
- 14.0 knots
- 78 US Gallons /hr
- 2,000 nm
Cruising:
- 12.0 knots
- 51 US Gallons /hr
- 2,750 nm
Economical:
- 10.0 knots
- 36 US Gallons /hr
- 3,241 nm
MACHINERY
Main Engines
Engine Type:
- (2) Caterpillar 3412, @ 1,400 Hp each
- Fully serviced by Anchors of America June 2024
- Walker Airsep turbo intake filters
Gearboxes for Main Engines: (2) Twin Disc MG-6556DC Ratio 3-1
Drive: (2) 4-bladed skewed 34”
Generators & Electricity
Generators:
- (2) Northern Lights 65Kw generators
- NEW Installed 2025
Shorepower: New transformer changed to 480v
Batteries:
- REPLACED 2025 - all main engine/generators
- NEW 2025 battery chargers
Air Conditioning
Type: 2 units- 120,000BTU and 90,000BTU
Other Machinery
Watermakers: (2) FEI MAX Q / 1275 GPD / NEW 2025 with piping replaced
Trim Tabs/Stabilizers: Wesmar 1600 2- Fin
Bow Thruster: NEW & UPGRADED 2025 with new bridge controls
Steering System: Hydraulic
Sewage System:
- Headhunter HMX- USCG approved
- Jet Vacuum heads, fresh water
Fresh Water System: NEW 2025 pumps & mainifolds
COMMUNICATION, NAVIGATION & ENTERTAINMENT SYSTEMS
Communication Systems
SATcom:G6 unit/gyro Trac
Telephone System: V11- HTS Dual Mode (voice/data)
VHF: ICOM M604
Cellular Phone System: digital 4000
WIFI: Wi-Fi access throughout for Owner, guests, crew, A/V equipment, Data from single panel Marine Starlink
LoudHailer: Furuno LH3000 to Engine room / forward & aft
Navigation Systems
Radar: (2) Furuno 1964c 12kw and 25kw
AIS:Furuno F-150
Sonar: Furuno CH250BB 88Kz
Gyrocompass: Simrad RGL 50
Auto Pilot: Simrad AP50
Depth Sounder: Furuno dual frequency 2kw
GPS:Furuno Navnet GPS32B receiver
Chart Plotter:Timezero electronic chart plotting system
Wind/Speed Log: B&G Hydra H1000 Wind Anemometer
Entertainment System:
- Sound and Video is fed throughout the boat on RTI T3X Wi-Fi enable remote controllers in each zone, there are also RTI KX3 wall controllers throughout for SONOS sound feed, streaming and DirectTV feed.
- Audio speakers throughout vessel
