CONSTRUCTION
Fiberglass hull and superstructure.
Skylounge aft deck, main aft deck, cockpit and swim platform are teak planked.
Side decks, foredeck and flybridge are non-skid.
FAVOR was extended from a 121’ to a 127’ after construction, making the aft deck larger and adding crew. Running gears were pushed back.
DIMENSIONS
General
Length Overall (L.O.A.): 127.11 feet (38.74 meters)
Beam (molded): 25.00 feet (7.62 meters)
Draft (loaded): 6.04 feet (1.84 meters)
Tonnage: 282 gross
Capacities
Fuel Capacity: 7,300 US Gallons (27,634 liters)
Water Capacity: 1,050 US Gallons (3,975 liters)
Holding: 350 US Gallons (1,325 liters)
Watermakers: 180 US Gallons /hour (681 liters /hour)
Speed, Consumption, Range & RPMs
Maximum:
- 18 knots
- Consumption per hours: 188
- RPM: 2350
Cruising:
- 15.5 knots
- Consumption per hours: 94
- RPM: 1850
Cruising
- 14.0 knots
- Consumption per hours: 60
- RPM: 1650
Cruising:
- 13 knots
- Consumption per hours: 42
- RPM: 1450
Economical:
- 9.8 knots
- Consumption per hours: 30
- RPM: 1300
MACHINERY
Main Engines
Engine Type: (2) MTU 16V-2000 M90 diesels @ 2,000 Hp each
Engine Hours:
- Port hours: 7,117 as of 03/26/2026
- Stbd. hours: 7,125 as of 03/26/2026
Gearboxes for Main Engines: ZF 3.481:1 Gear ratio
Generators & Electricity
Generators: (2) Northern Lights M439T
Generators Output: 55 kW
Generator Hours:
- Port hours: 1,560 as of 03/31/2026 - Since major overhaul 04/2025
- Stbd. hours: 23,000 as of 03/31/2026
Emergency Generator: (1) Northern Lights NL378K
Emergency Generator Output: 10 kW – 40 hours as of 03/31/2026
Shore Power: Atlas Classic 50 kVA power converter
PTO’s: Off both generators
AC Power: (1) 100 Amp three-phase 480 shore cord or (2) 100 Amp three-phase 208 shore cords
Converter:
- Newman 32-12-50 DC converter
- Atlas Shore Power Classic Frequency converter
Batteries:
- (6) 8 AGM
- (8) 6 VDC 9 AGM
- (4) Group 27 AGM
DC Electrical System: 24V and 12V
Air Conditioning
Type: Marine Air 4 compressor (60,000 BTU’s) tempered water system with 22 air handler
Other Machinery
Spot Zero: Dometic Spot Zero
Watermakers: (2) Village Marine 2000GPD
Stabilizers:
- Naiad Dynamics 2021 model 404
- New seals in 2025
Bow Thruster:
- American Bow Thruster
- Robertson FU91 bow thruster control
Steering System: Robertson RI9 - Hydraulic
Fuel Separator & Filtration: Separ SWK 2000
Sewage System:
- Headhunter 301
- Vacuflush system
- Keel laid black water tank
Fresh Water System:
- (2) Village Marine 2000GPD
- Rheem 50-Gallon water heater
- (3) 30-Gallon electric water heaters
Bilge Water Filtration:
- (2) Baldor fire/bilge pumps
- (1) Rule 3000 for engine room
COMMUNICATION, NAVIGATION & ENTERTAINMENT SYSTEMS
Communication Systems
VHF:
AIS: Furuno FA 170 AIS
Intercom: Seahail system
Navigation Systems
Pilothouse
Radar/GPS/Chart Plotter:
- (1) 16” Garmin
- (1) 12” Garmin
Flat Screen Displays: (2) 18” Garmin for navigations, sonar, radar and CCTV
Depth Sounder: (2) 8" Garmin for depth, wind, and speed
Magnetic Compass: Richie
Auto Pilot: Simrad AP 70 MK2
Navtex: Furuno
Engine Displays: (2) DDEC
Engine Controls: DDEC controls
Spotlight: ACR spot light control
Entertainment System:
TV’s:
- (1) 55” Samsung – Salon
- (1) 50” Samsung – Skylounge
- (1) 24” Vizion – Galley
- (1) 32” Sony – Master Stateroom
- (1) 24” Samsung – VIP Guest Stateroom/Mid ship Forward Port
- (1) 24” Samsung – VIP Guest Stateroom/Forward Starboard
- (1) 24” Samsung – VIP Guest Stateroom Port Aft
- (1) 24” Samsung – Twin Guest Stateroom /Starboard Aft
- (1) Samsung – Crew Mess
Stereo’s: Speakers (crew mess)
