CONSTRUCTION
Steel hull, aluminum superstructure, teak decks
DIMENSIONS
General
Length Overall (L.O.A.):
- 163.72 feet
- (49.90 meters)
Beam (molded):
Draft (loaded):
Tonnage: 480 gross
Capacities
Fuel Capacity:
- 22,375 US Gallons
- (84,700 liters)
Water Capacity:
- 6,119 US Gallons
- (23,162 liters)
Black Water:
- 599 US Gallons
- (2,266 liters)
Grey Water:
- 3,817 US Gallons
- (14,450 liters)
Watermakers: (2) Octo Marine Deepblue T8-8m3/day
Fuel Consumption
Fuel Consumption for 2 ME: 180 l/hr at cruising speed (12 knots)
Fuel Consumption for 2 ME: 320 l/hr at top speed (15 knots)
MACHINERY
Main Engines
Engine Type: (2) Caterpillar 3508 DI-TA diesels @ 1,100 Hp each
Gearboxes for Main Engines: Reintjes WAF 541
Drive: (2) Teignbridge 5 blade propellers
Generators & Electricity
Output: 220V 50hz / 300V 50hz 3phase
Generators: Caterpillar 3306BT
Generator Fuel Consumption: 20 l/hr
Shore Power: 120 / 380V 1&3phase 50/60hz
Converter: Atlas 80Kw
Batteries: 24V
Air Conditioning
Type: Condaria WM-RE 120002
Other Machinery
Watermakers: (2) Octo Marine Deepblue T8-8m3/day
Trim Tabs/Stabilizers: Quantum Zero Speed
Bow Thruster: CRAMM V2 20H
Steering System: Ulstein JR 2.130 (Total Rebuild 6/2024)
Fuel Separator & Filtration: Alfa Laval MAB 103B
Sewage System: Hamann Type 2
Fresh Water System: C-PVC
Bilge Water Filtration: Heli Sep HS-500 OCD Bilge Water Separator (6/2021)
COMMUNICATION, NAVIGATION & ENTERTAINMENT SYSTEMS
Communication Systems
SATcom: Starlink
Telephone System: Panasonic
SSB: MF/HF DSC Radio set
VHF: (2) Sailor 6222 VHF DSC
Cellular Phone System: Kerio System with Sim Cards & Google Phones
Intercom: Panasonic
Navigation Systems
Radar:
- (1) FURUNO FAR22x8BB with (1) Furuno 8' Open Array Antenna, X-Band (1)
- Furuno XN20CF/6.5 6.5' Open Array Antenna, X-Band (6/2023)
Gyrocompass: Anschutz STD22 (Sphere replaced 4/2024)
Magnetic Compass: Cassens & Plath Delta (4/2024)
Auto Pilot: Anschutz Pilotstar D
Echo Sounder: ELAC LAZ 5100
GPS: Simrad A170 + Furuno GP170
Weather FAX: B & G Hydra 2000
Laser Plotter: Transas
Wind/Speed Log: Consilium SAL R1
Navtex:
- Sailor TT-3606E / Navtex Receiver / Printer
- NX700P
AIS: Simrad
Chart Display: Transas Navi Sailor 4000 MFD
BNWAS: Foruno BR500PA Pilothouse Alerter System
Entertainment Systems
Video & Audio Equipment
- AV system with HD screens throughout the yacht updated with new releases (2023)
- Full surround sound cinema with pop up screen in the main saloon
- Plasma or liquid crystal flat screen TV's throughout the yacht - makes and sizes below:
- Sky Lounge - flat screen LED Samsung 55"
- Master cabin - flat screen Pioneer TV 41"
- All other cabins - flat screen Sony TV 20"
- Sky TV (Mediterranean)
- Audio on demand system available throughout the yacht (inside & outside)
- Sound server and iPAD docking stations in both saloons and all cabins
